Protective Braids
Providing durable protection from the extreme temperatures present aboard spacecraft, Gore’s Protective Braids increase the reliability of signal integrity and offer easy installation in tight areas.
Nous contacter
+1 800 626 7708
Germany
+49 9144 6010
+49 9144 6816 (fax)
UK
+44 1382 56 1511
+44 1382 56 1007 (fax)
Italy
+39 045 6209 209
+39 045 6209 165 (fax)
France
+33 1 5695 6565
+33 1 5695 6401 (fax)
Spain
+34 93 480 6900
+34 93 373 7850 (fax)
Sweden
+46 31 7067800
+46 31 864226 (fax)
China (Beijing)
+86 10 5707 4999
+86 10 5707 4900 (fax)
China (Shanghai)
+86 21 5172 8299
+86 21 6247 9199 (fax)
China (Shenzhen)
+86 755 8359 8262
+86 755 8359 1654 (fax)
South Korea
+82 2 393 3411
+82 2 393 1285 (fax)
Japan
+81 3 6746 2582
+81 3 6746 2571 (fax)
Infothèque
Catalog: GORE® Space Cables for Traditional Space Applications
Product Selection Guides, 4.33 MB
Due to operating conditions in space that are the harshest imaginable, space programs must have complete confidence that the cables connected to critical systems will continue to perform under that stress. And because repairs are not easy to make outside of planet Earth, these cables must not only be rugged but also boast decades of proven success. That’s where GORE® Space Cables for Traditional Space Applications from W. L. Gore & Associates come into play.
Overview
The extreme temperatures inherent in spacecraft can impair cables and their performance, so critical to any space mission.
Gore offers protective braids installed over cable bundles that provide durable protection in extreme temperatures, and enhanced EMI suppression for reliable signal integrity. Our high-strength braids are also smaller and more flexible than competitors’ braids, allowing for easier routing in the tight areas of a spacecraft.
Features & Benefits
Protective Braids from Gore feature an:
- ePTFE construction
- smaller and more flexible construction than competitors’ braids
- enhanced EMI suppression
These features benefit manufacturers and end users by providing:
- easy routing in tight areas
- increased reliability of signal integrity
Additionally, Gore’s worldwide engineering team provides sales and technical support. If you have any questions about the space cables’ features or benefits, please contact us.
Specifications
Protective Braids from Gore meet these technical specifications:
| Braid Type | Plating | Operating Temperature |
|---|---|---|
| ePTFE | N/A | -200°C to +260C° |
| Copper | Silver (2.5μm min.) | -200°C to +200C° |
| Copper | Nickel (1.2 μm min.) | -200°C to +260C° |
| ePTFE over copper | Silver (2.5μm min.) | -200°C to +200C° |
| ePTFE over copper | Nickel (1.2 μm min.) | -200°C to +260C° |
Resources
Learn more about our Protective Braids in the product brochure and a white paper discussing the properties of cables that ensure peak electrical performance.
Catalog: GORE® Space Cables for Traditional Space Applications
Product Selection Guides, 4.33 MB
